High Performance ● Regeneration Function: The battery will withdraw electricity automatically when decelerating or parking. ● Reliable AC Technology: American Curtis controller and KDS motor provide the infinite variable drive and lift control. The brush-less AC motors offer improved efficiency and reduce maintenance cost. ● CAN bus communications network: provides superior dependability. ● Shimadzu pump and valve ensures the reliability and stability of hydraulic system. ● EPS(electronic steering system): light steering, shows the driving wheel position in real-time. Automatic centering function when starts. |
|
Safety& Ergonomics ● Turning automatic deceleration function to prevent the forklift from turning over when turning, making the operation safer. ● Automatic parking function. ● German imported steel for mast with high strength and high wear resistance. ● Wide view mast and strong OHG. |
 |
 |
Easy Maintenance ● Maintenance free AC Motor makes forklift release less heat and ensures higher efficiency. ● Simple structure and maintenance free components decrease maintenance cost. ● The removable maintenance cover helps to access to the controller and other key parts easier. |
| Specification |
1 |
Manufacturer |
|
UN |
|||
|
2 |
Model |
|
FBR15-NQC3 |
FBR18-NQC3 |
FBR20-NQC3 |
FBR25-NQC3 |
|
|
3 |
Power |
|
Battery |
||||
|
4 |
Operation |
|
Stand-on |
||||
|
5 |
Rated Load Capacity |
Q(kg) |
1500 |
1800 |
2000 |
2500 |
|
|
6 |
Load Centre |
C (mm) |
500 |
500 |
500 |
500 |
|
|
7 |
Lift Height |
H3 (mm) |
4000 |
4000 |
4000 |
4000 |
|
|
8 |
Free Lift |
H2 (mm) |
1010 |
1010 |
1010 |
910 |
|
|
9 |
Fork Size (LxWxT) |
L/W/T(mm) |
920x120x35 |
1070x120x40 |
1070x120x40 |
1070x120x40 |
|
|
10 |
F/B(a°/β°) |
Deg |
2°/4° |
||||
|
Dimensions |
11 |
Overall Length (without fork) |
L1 (mm) |
1800 |
1885 |
1885 |
1885 |
|
12 |
Main Body Length |
L2 (mm) |
1260 |
1270 |
1270 |
1330 |
|
|
13 |
Width |
B1 (mm) |
1090 |
1200 |
1200 |
1200 |
|
|
14 |
Mast Lowered Height |
H1 (mm) |
1975 |
1975 |
1975 |
1875 |
|
|
15 |
Mast Extended Height (With Backrest) |
H4 (mm) |
5705 |
5705 |
5705 |
5405 |
|
|
16 |
Overhead Guard Height |
H5 (mm) |
2310/2255 |
||||
|
17 |
Turning Radius |
Wa (mm) |
1660 |
1660 |
1750 |
1920 |
|
|
18 |
Ground Clearance |
H6 (mm) |
94 |
94 |
82 |
82 |
|
|
19 |
Reach Distance |
X (mm) |
560 |
560 |
640 |
670 |
|
|
20 |
Wheelbase |
Y (mm) |
1370 |
1370 |
1485 |
1655 |
|
|
21 |
Front Tread |
B2 (mm) |
1005 |
1005 |
1080 |
1080 |
|
|
22 |
Rear Tread |
B3 (mm) |
625 |
625 |
705 |
705 |
|
|
23 |
Working Aisle Width With Pallet (1000x1200，1200 Lengthways) |
Ast(mm) |
2715 |
2715 |
2750 |
2850 |
|
|
24 |
Working Aisle Width With Pallet (800*1200，800 Lengthways) |
Ast(mm) |
2760 |
2760 |
2780 |
2855 |
|
|
Performance |
25 |
Travel Speed (Full Load) |
km/h |
9.5 |
|||
|
26 |
Travel Speed (No Load) |
km/h |
10 |
||||
|
27 |
Lifting Speed (Full Load) |
mm/s |
320 |
320 |
300 |
280 |
|
|
28 |
Max gradeability (Full Load) |
% |
12 |
10 |
10 |
10 |
|
|
29 |
Total Weight (Contains the battery) |
Kg |
2440 |
2440 |
2510 |
2625 |
|
|
30 |
Front x 2 |
|
250x85 |
250120 |
|||
|
31 |
Rear x 1 |
|
300x135 |
343x135 |
|||
|
32 |
Balance |
|
178x76 |
||||
|
Drive |
33 |
Diver Motor |
kw |
4.5 |
|||
|
34 |
Pump Motor |
kw |
12.5 |
||||
|
35 |
Battery (Standard) |
V/Ah |
48/375 |
48/375 |
48/425 |
48/425 |
|
|
36 |
Steering System |
|
Eletronic Power Steering |
||||
|
37 |
Service Brake |
|
Electromagnetic Brake |
||||
|
38 |
Controller Type |
|
AC |
||||
|
39 |
Controller Manufacturer |
|
Curtis |
||||
Specifications and characteristics are subject to change without notice.
Please contact us for detailed information.
