Electric Pallet Stacker CL20GA

Get brochure

Product Description

This series delivers reliable power, smooth control, and stable performance for efficient material handling. Designed with durability and safety in mind, it is well-suited for demanding industrial and logistics applications.

E-mail: [email protected]

Product Details

MAIN SPECIFICATIONS

Model		CL2016GA	CL2025GA	CL2030GA	CL2033GA	CL2036GA
Rated Load Capacity	Q(t)	2.0	2.0	2.0	2.0	2.0
Load Centre	c (mm)	600	600	600	600	600
Wheelbase	y (mm)	1332	1332	1332	1332	1332
Total Weight（with battery）	kg	960	1035	1090	1115	1135
Height of Mast（lowered）	h1 (mm)	1990	1741	1991	2141	2291
Overall length	l1 (mm)	2040	2040	2040	2040	2040
Overall Width	b1/ b2 (mm)	808	808	808	808	808
Min Turning Radius	Wa (mm)	1570	1570	1570	1570	1570
Travel Speed（Full Load / No Load）	(km/h)	5.2/5.5	5.2/5.5	5.2/5.5	5.2/5.5	5.2/5.5
Max.Gradeability（Full Load / No Load）	(%)	6/8	6/8	6/8	6/8	6/8
Battery	(V/Ah)	24/210	24/210	24/210	24/210	24/210

Product Features

High Performance
- High-power MOSFET driver. High-frequency, efficient, quiet, stepless speed regulation and reverse braking function.
- Advanced vertical AC drive system, motor can get more energy and greater brake torque, more powerful and efficient, accelerated performance is better.
- The whole series is configured with a special gantry steel, great plasticity, strong anti-bending ability; high structural stability.
- The whole series equipped with a standard steering system, the assisted power is responsive and the handle is easy to operate.
- The number of components required for the AC motor is little. There are no fragile components that need to be replaced regularly, almost no maintenance, it is more efficient and durable.
- Equipped with side pull battery configuration, battery replacement is faster and more convenient, easier for continuous operation, greatly improve work efficiency.
- The standard configuration is lifting limit, when the fork rises to the top, the system automatically cuts off the uplink power supply, smooth parking, effective prevent the occurrence of “roof falling” accidents.
